METAM LV
Metallurgical Microscope
Description
Best choice for expert of Materials Micro who requires high-performance optical tool.
It also supplies the best optical performance for material research, quality control,
Invalidation Analysis and other applications.
Specification
|
METAM LV |
||
|
Optical System |
Infinite optical system |
● |
|
Extral Wide Field Eyepiece |
EW10×/20 |
● |
|
EW10×/20 Eyepiece with scale of cross hair |
● |
|
|
EW15×/16 |
○ |
|
|
EW20×/12 |
○ |
|
|
Infinite Plan |
5×/0.17/∞/- (BF/DF)WD 8.6mm |
● |
|
10×/0.28/∞/-(BF/DF)WD 3.4mm |
● |
|
|
20×/0.5/∞/0(BF/DF)WD 1.1mm |
● |
|
|
50×/0.85/∞/0(BF/DF)WD 0.5mm |
● |
|
|
100×/0.95(Dry)/∞/0(BF)WD 0.1mm |
● |
|
|
100×/1.32(Oil)/∞/0(BF)WD 0.1mm |
○ |
|
|
Viewing Head |
Siedentopf trinocular viewing head, inclined at 30° |
● |
|
Kohler Incident Light |
12V/100W Halogen light, Center and brightness adjustable |
● |
|
Polarizer and analyzer |
● |
|
|
DIC |
○ |
|
|
Built-in Green, Blue, Yellow, Gray and ground glass |
● |
|
|
Focusing |
Coaxial coarse and fine adjustment, fine division 2μm |
● |
|
Nosepiece |
Quintuple nosepiece |
● |
|
Stage |
Double layer mechanical stage 200×190mm，Moving range 40mm×40mm |
● |
|
Stage: Φ16, Φ40, Teardrop |
● |
|
|
Accessories |
Photo/Video attachment |
○ |
|
0.01mm? Micrometer scale 0.01mm |
● |
Note: ● Standard Outfit, ○ Optional
