NGI-6
Stereo Microscope
Description
Offering crisp sharp and high resolution image with High brightness LED point
light，dark field illumination and even fluorescent light source,it is a high
level professional Gem Microscope.
Updated and ergonomic design, it makes operators feel more comfortable
Specification
|
NGI-6 |
||
|
Stereo Zoom Body |
Zoom objective 0.8X-5X, Zoom ratio 1：6.3, Working distance 115mm |
● |
|
Eyepiece |
Extra wide field eyepiece WF15X/Φ16 with diopter adjustment |
● |
|
Bright & Dark |
Iris diaphragm 2mm-41mm,Bright and dark viewing field illumination adjustable |
● |
|
Viewing Field |
||
|
Illumination |
||
|
Illumination |
7W Fluorescent lamp |
● |
|
LED Point Light |
● |
|
|
6V/20W Halogen illumination |
● |
|
|
Focusing |
Focusing range: 110mm |
● |
|
Suitable for observing different size gem and sample |
||
|
Gem Clamp |
Quality steel clamp to hold the gem for all direction observations of gems |
● |
|
Stage |
Two gem clamp fixing holds for you to choose |
● |
|
Stand |
0-38°Rotatable, eyepoint height and angle adjustable |
● |
|
Base |
0°-325°Rotatable |
● |
