WZZ-3
Automatic Polarimeter
Characteristics
• Measuring specific rotation, optical rotation, concentration and sugar degree .
• Automatic repetition-measurement for 6 times, and calculation of average value and means square root.
• USB.
Specifications
|
Parameters/Model |
WZZ-3 |
|
Measurement modes |
Optical rotation, specific rotation, sugar degree, concentration |
|
Light source |
LED + interference filter |
|
Wavelength |
589nm |
|
Measurement range |
±45°（optical rotation）, 120°Z(sugat) |
|
Accuracy |
±(0.01+measuring value ×0.05%)°（optical rotation） |
|
Repeatability |
≤0.003°（optical rotation） |
|
Display |
Color Touch LCD |
|
Minimum indicating value |
0.001° |
|
Test tubes |
100mm / 200mm (regular) |
|
Transmission |
10% |
|
Interface |
USB |
|
Weight (Gross) |
36kg |
|
Overall Dimensions |
730mm×480mm×470mm |
