DYY-3C
Electrophoresis Power Supply
Feature:
1.OutputModes: Constant Voltage (CV), Constant Current (CC), Constant Power (CP).
2.One-Touch Setup: One-click protein mode setup—automatically switches from stacking gel to resolving gel phase without manual reset, simplifying operation.
3.SmartTriple Constant Control: Set any constant value (voltage, current, or power); the other two are automatically limited to prevent overload, ensuring dynamic triple-constant operation.
4.Micro-Current Maintenance: After electrophoresis ends, the system can automatically switch to micro-current mode to prevent sample diffusion or overrun during unattended operation.
5.Large Display: 4.3-inch touchscreen with real-time touch control, showing voltage, current, power, and time simultaneously; both preset and actual values are clearly visible.
6.User-Friendly Interface: Intuitive, smartphone-like interface for simple and efficient operation.
7.Power-Out Recovery: Automatically memorizes the running state during a power failure, and resumes the process upon power restoration.
8.AutoMemory &Shutdown: Features automatic memory and auto power-off functions
9.Wide Input Voltage Range: AC 110V–240V, 50/60Hz input, highly adaptable to global power standards.
10.MethodStorage: Programmable storage of up to 20 methods, each with up to 10 steps
11.Safety Features: Over voltage, arc, no-load, and sudden load change detection; overload/short-circuit monitoring; leakage protection; open-circuit alarms
Application:
Used for horizontal, vertical, and blotting experiments.
Specification:
Dimension (LxWxH) 377 x 270 x 122mm
Output Voltage: 2-300V
Output Current: 2-400mA
Output Power: 120W
Output Terminal: 4 pairs in parallel
Input Power :AC110V-240V 50/60Hz
Weight: 3.5k
